Cloud Electronics CS-S8ADW & CS-S8ADB

  • 8″ treated paper woofer with 1″ compression driver in a 2-way coaxial design
  • Frequency response: 75Hz – 20kHz (-3dB)
  • Coverage: 100° average (2–10kHz)
  • Sensitivity: 92dB (1W/1m), Max SPL: 116dB
  • Built-in 2-channel Class D amplifier with DSP bi-amped crossover
  • Dante® / AES67 network input on RJ45 (2-channel receiver)
  • 5 EQ presets, master level control, mono/stereo switch
  • Link output on XLR and Euroblock for extra speakers
  • Full protection: over-temperature, DC, HF and over-current; IEC mains
  • Rugged, recyclable LLDPE enclosure with steel grille, for indoor or outdoor use
  • Mount vertically or horizontally: integrated pole mount, M6 points, safety tie-off point
  • Optional U-bracket: CS-810BKTB/W
  • Available in Black (RAL 9011) or White (RAL 9003)
  • Dims: 429 x 273 x 265mm (h x w x d)
  • Weight: 8.76kg net
Last modified: October 13th, 2026
by Sound Productions Ltd

The CS-S8AD is the networked, self-powered version of Cloud’s new 8-inch CS-S Series loudspeaker. It takes audio straight from a Dante® or AES67 network, with its own Class D amplifier and DSP on board. Every size in the CS-S range shares the same acoustic signature, so 8″, 10″ and 12″ models can be mixed in one venue to match each area’s SPL needs while sounding consistent throughout. The coaxial drivers deliver a wide, even coverage pattern with strong low-frequency output for both background and foreground music.
